DMP 339

The DMP 339 industrial pressure transmitter from BD Sensors features a G ¼" flush pressure port and was specifically designed for usage in a range of machinery including metering systems. This transmitter is perfect for measuring the pressure of viscous and pasty media, as only a small dead space is created.

To increase the effectiveness and reliability of your machines the following has been eliminated:

  • Material accumulation
  • Dripping
  • Stringing.

For sales or commercial inquiries please contact us at marine@insatech.com.

Contact us now

Standard DMP 339 Features

The DMP 339 pressure transmitter is precise and has the following features that benefits you:

  • Nominal pressure: 0 ... 60 bar up to 0 ... 600 bar
  • Accuracy: 0.35 % FSO
  • Suited for viscous and pasty media
  • Mechanical connection: G ¼‘‘ flush.
DMP339 Bdsensors 1024X16x9

Typical applications

The DMP 339 from BD Sensors is applicable in various settings including:

  • Maritime industry
  • Mechanical and plant engineering
  • Hydraulics.

Get more information here

Additional Available Features

If you have a specific need the DMP 339 pressure transmitter is available with optional features like:

  • IS-version Ex ia = intrinsically safe for gases and dusts
  • Several kinds of electrical connections
  • Customer specific versions.

To ensure an exceptional adaption to various application conditions the DMP 339 is available with various electrical connections, as mentioned above.



Does it match your need - contact us here

BD Sensors Logo Overview
Insatech Medarbejdere Website MSR
For technical questions

Martin Søvind Jensen

Tel: +45 2761 4502

Email: Martin.Sovind@insatech.com

Write to Martin

Insatech Medarbejdere Website ASMI
For commercial inquiries

Astrid Mihut

Tel.: +45 5537 2095

Email: Marine@insatech.com



Contact us now

Model/ Type
Pressure

135: gauge

136: absolute
Input [bar] (Note 1)

6002: 60

1003: 100

1603: 160

2503: 250

4003: 400

6003: 600 (Note 2)

9999: customer
Output

1: 4 … 20 mA / 2-wire

2: 0 … 20 mA / 2-wi3e

3: 0 … 10 V / 3-wire

E: intrinsic safety 4 … 20 mA / 2-wire

9: customer
Accuracy

3: 0.35 % FSO

9: customer
Electrical connection

100: male and female plug ISO 4400

200: male plug Binder series 723 (5-pin)

TA0: cable outlet with PVC cable (IP67) (Note 3)

TR0: cable outlet, cable with ventilation tube (IP68) (Note 4)

M10: male plug M12x1 (4-pin) / metal

850: compact field housing stainless steel 1.4301 (304)

999: customer
Mechanical connection

F02: G1/4" DIN 3852 with flush sensor

999: customer
Seals

1: FKM

9: customer
Special version

000: standard

999: customer
Notes

1: nominal pressure gauge pN < 60 bar on request
2: nominal pressure 600 bar without UL certification
3: standard: 2 m PVC cable without ventilation tube (permissible temperature: -5 … 70°C), others on request
4: code TR0 = PVC cable, cable with ventilation tube available in different types and lengths
