DCT 571
The DCT 571 is a pressure transmitter from BD Sensor, which is specifically designed for various measurements as for example pressures or levels of pasty, and contaminated or aggressive media.
Furthermore, this pressure sensor is made of 99,9% pure ceramic, which is characterized by:
For sales or commercial inquiries please contact us at marine@insatech.com.
The DCT 571 pressure transmitter is precise and has the following features that benefits you:
Furthermore, you will get a reliable and vigorous data transmission because of the integrated interface RS485 (based on the MODBUS RTU protocol). Thus, this transmitter will word without difficulties over longer distances as well.
Moreover, the DCT 571 is connected directly to a master e.g., is coupled to a SPS, which means that the conversion losses you might experience of an analog input card are avoided.
The DCT 571 from BD Sensors is applicable in various settings:
If you have a specific need the DCT 571 pressure transmitter is available with optional features like:
| Model/ Type | |||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Pressure | 285: gauge in bar 286: absolute in H2O |
||||||||||||||||||
| Input | [mH2O] [bar] 1000: 0.10 |
||||||||||||||||||
| Output | L5: RS485 Modbus RTU |
||||||||||||||||||
| Accuracy | standard 3: 0.35 % FSO option 2: 0.25% FSO 9: customer |
||||||||||||||||||
| Electrical connection | N11: male plug M12x1 (5-pin) / metal 999: customer |
||||||||||||||||||
| Mechanical connection (Note 1) | 100: G1/2" DIN 3852 200: G1/2" EN 837 300: G1/4" DIN 3852 400: G1/4" EN 837 K00: G3/4" with flush sensor 999: customer
|
||||||||||||||||||
| Seal | 1: FKM 3: EPDM 7: FFKM 9: customer |
||||||||||||||||||
| Pressure port | 1: stainless steel 1.4404 (316L) B: PVDF (Note 2) R: PP-HT (Note 2) 9: customer |
||||||||||||||||||
| Diaphragm | C: ceramics Al2O3 99.9 % 9: customer |
||||||||||||||||||
| Special version | 03P: standard 999: customer |
||||||||||||||||||
| Notes | 1: metric threads and others on request 2: only for mechanical connection G3/4"; for pressure port in PVDF or PP-HT the operation medium temperature is -30 … 60 °C |
||||||||||||||||||
If you are looking for some specific material, please write to us. Then we will try to find it for you, and send it as soon as possible.
