DCT 531P

The DCT 531P is a pressure transmitter from BD Sensors has a compact design, which is available in hygienic versions. This guarantees an exceptional performance in terms of:

  • Accuracy
  • Thermal behavior
  • Long-term stability.

For sales or commercial inquiries please contact us at marine@insatech.com.

Contact us now

Standard DCT 531P Features

The DCT 531P pressure transmitter is precise and has the following features that benefits you:

  • Nominal pressure: 0 ... 100 mbar up to 0 ... 400 bar
  • Accuracy: 0,25 % FSO
  • Output signal: RS485 with Modbus RTU Protocol
  • CIP / SIP cleaning up to 150 °C
  • Diaphragm with low surface roughness
  • Reset function
  • Ingress protection IP 67 / IP 69.

You will get a reliable and vigorous data transmission because of the integrated interface RS485 (based on the MODBUS RTU protocol). Thus, this transmitter can function failure-free even over long distances.

Typical applications

The DCT 531P from BD Sensors is applicable in various settings:

  • Maritime industry
  • Food/ beverage industry
  • Pharmaceutical industry.

Get more information here

Additional Available Features

If you have a specific need the DCT 531P pressure transmitter is available with optional features like:

  • Different process connections
  • Cooling element for media temperatures up to 300 °C.

The transmitter is using a modular concept, which makes it possible for you to customized electrical or mechanical connections. Thus, the DCT 531P is easily adapting to various conditions on-site.

Does it match your need - contact us here

For technical questions

Martin Søvind Jensen

Tel: +45 2761 4502

Email: Martin.Sovind@insatech.com

Write to Martin

For commercial inquiries

Astrid Mihut

Tel.: +45 5537 2095

Email: Marine@insatech.com



Contact us now

Model/ Type
Pressure

501: gauge

502: absolute
Input [bar]

1000: 0.10 (Note 1)
1600: 0.16 (Note 1)
2500: 0.25 (Note 1)
4000: 0.40
6000: 0.60
1001: 1.0
1601: 1.6
2501: 2.5
4001: 4.0
6001: 6.0
1002: 10
1602: 16
2502: 25
4002: 40
x102: -1 ... 0
9999: customer
Output

L5: RS485 Modbus RTU
Accuracy

2: 0.25% FSO

9: customer
Electrical connection

N11: male plug M12x1 (5-pin) / metal

999: customer
Mechanical connection

Z00: G1/2" DIN 3852 flush (pN ≥ 1 bar)

ZS1: G1" DIN 3852 flush

KS1: G 1" cone

C61: Clamp DN 25 DIN 32676 (pN ≤ 16 bar)

C62: Clamp DN 32 DIN 32676 (pN ≤ 16 bar)

P41: Varivent® DN 40/50 (pN ≤ 25 bar)

999: customer


Diaphragm

1: stainless steel 1.4435 (316L)

9: customer
Seal

for clamp, Varivent®

0: without

for inch thread - standard

1: FKM

for inch thread - option

7: FFKM

9: customer
Filling fluid

1: silicone oil

2: food compatible oil (FDA)

9: customer
Special version

03P: standard

23P:with cooling element up to 300°C

999: customer
Notes

1: absolute pressure possible from 0.4 bar

Varivent® is a brand name of GEA Tuchenhagen GmbH.
