VEGAPULS 21 is the ideal sensor for non-contact level measurement of liquids and bulk solids in simple applications. It is universally applicable, as it can be supplied with numerous approvals within marine, drinking water, food, pharma, overfill protection and ATEX.
Measuring range up to 15 m.
For sales or commercial inquiries please contact us at marine@insatech.com.
4...20 mA / HART output, measuring range up to 15 m, accuracy ±2 mm, Ex approval
It is particularly suitable for use in water treatment, storage tanks with acids, lyes and additives in all industrial areas, or for measuring levels in plastic tanks from the outside through the tank wall. In bulk solids the sensors are used in small bulk solids silos or open containers.
| Technical Specifications | |||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Measuring range - Distance | 15 m |
||||||||||||||||||
| Process temperature | -40...+80 °C |
||||||||||||||||||
| Process pressure | -1...+3 bar |
||||||||||||||||||
| Accuracy | ±2 mm |
||||||||||||||||||
| Frequency | 80 GHz |
||||||||||||||||||
| Beam angle | 8° |
||||||||||||||||||
| Output | 4…20 mA / HART |
||||||||||||||||||
| Protection rating |
|
||||||||||||||||||
| Ambient temperature | -40...+70 °C |
||||||||||||||||||
| Materials, wetted parts | PVDF |
|---|---|
| Seal material | FKM |
| Housing material | Plastic |
| Threaded connection |
|
|---|
| Scope |
|
|---|---|
| Explosion protection | Intrinsic safety "i" |
| Foodstuffs/Pharma |
|
| Ship approval |
|
| Overfill protection |
|
If you are looking for some specific material, please write to us. Then we will try to find it for you, and send it as soon as possible.
High quality and robust mounting strap made of 316L stainless steel. The adjustable sensor holder allows easy alignment of the sensors. The mounting strap is particularly suitable for VEGAPULS 11, 21, 31 and C 11, C 21, C 22, C 23 series radar sensors and VEGAPULS Air 41, but can also be used for other instruments with appropriate process fittings. The necessary mounting material for wall mounting of 316L is supplied with the instrument.
The adjustable bracket allows easy mounting of the sensors and safe access for maintenance work. The mounting strap is particularly suitable for VEGAPULS 11, 21, 31, VEGAPULS C 11, C 21, C 22, C 23 and VEGAPULS Air 41 radar sensors, but can also be used for other instruments with appropriate process fittings.
HYGADAPT-R is a hygienic adapter (G1½“), which is suitable for VEGAPULS 11, 21, 31, VEGAPULS C 11, C 21, C 22 and VEGAPULS Air 41.
