LMP 331i
The LMP 331i from BD Sensors is a precision screw-in transmitter where the signal processing is done with a 16-bit analog digital converter. Consequently, you can conduct an active compensation.
Moreover, the transmitter is exceptional in measuring and is cost-effective.
For sales or commercial inquiries please contact us at marine@insatech.com.
The screw-in transmitter LMP 331i is precise and has the following features that benefits you:
The LMP 331i from BD Sensors is applicable in various settings:
The probe can also be used for various media including fuels and oils, as well as water and gases.
If you have a specific need the screw-in transmitter LMP 331i is available with optional features like:
| Model/ Type | |||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Pressure | 430: in bar 431: in H2O |
||||||||||||||||||
| Input | [mH2O] [bar] 4000: 0.4 |
||||||||||||||||||
| Output | 1: 4 … 20 mA / 2-wire E: intrinsic safety 4 … 20 mA / 2 wire 3: 0 … 10 V / 3-wire 9: customer |
||||||||||||||||||
| Accuracy (at nominal pressure) | 1: 0.1 % FSO 9: customer |
||||||||||||||||||
| Electrical connection | 100: male and female plug ISO 4400 200: male plug Binder series 723 (5-pin) A00: male and female plug Binder series 723 (7-pin) M10: male plug M12x1 (4-pin) / metal for analog output M13: male plug M12x1 (4-pin) / metal for digital output TA0: cable outlet with PVC cable (IP67) (Note 1) TR0: cable outlet, cable with ventilation tube (IP68) (Note 2) 850: compact field housing stainless steel 1.4301 (304) 999: customer |
||||||||||||||||||
| Mechanical connection | K00: G3/4" DIN 3852 with flush sensor 999: customer |
||||||||||||||||||
| Seals | 1: FKM 9: customer |
||||||||||||||||||
| Special version | 111: standard 121: communication interface RS232 (Note 3) 999: customer |
||||||||||||||||||
| Notes | 1: standard: 2 m PVC cable without ventilation tube (permissible temperature: -5 ... 70 °C); others on request 2: code TR0 = PVC cable, cable with ventilation tube available in different types and lengths 3: Communication interface RS232 only possible with el. connection Binder serie 723 (7-pin) Software, Interface and cable for LMP 331i with option RS-232 have to be order separately (Ordering code: CIS-G; Software appropriate for Windows® 95, 98, 2000, NT Version 4.0 or newer and XP) |
||||||||||||||||||
If you are looking for some specific material, please write to us. Then we will try to find it for you, and send it as soon as possible.
