LMP 308
The LMP 308 from BD Sensors is a detachable stainless-steel probe, which is designed to measure the level continuously in water and thin fluids. Moreover, the transmitter head is plugged to the cable assembly with a connector, which makes it easy to change, as well as stockkeeping and maintenance.
For sales or commercial inquiries please contact us at marine@insatech.com.
The LMP 308 submersible probe is precise and has the following features that benefits you:
The LMP 308 from BD Sensors is applicable in various settings:
Moreover, the probe can be used for various media including water.
If you have a specific need the LMP 308 submersible probe is available with optional features like:
| Model/ Type | |||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Pressure | 440: in bar 441: in H2O |
||||||||||||||||||
| Input | [mH2O] [bar] |
||||||||||||||||||
| Housing | 1: stainless steel 1.4404 (316L) 9: customer |
||||||||||||||||||
| Diaphragm | 1: stainless steel 1.4435 (316L) 9: customer |
||||||||||||||||||
| Output | 1: 4 … 20 mA / 2-wire E: intrinsic safety 4 … 20 mA / 2-wire 1S: SIL2 4 … 20 mA / 2-wire ES: SIL 2 with Intrinsic safety, 4 … 20 mA / 2-wire 9: customer |
||||||||||||||||||
| Seals | 1: FKM 3: EPDM 9: customer |
||||||||||||||||||
| Electrical connection | 1: PVC-cable (grey, Ø 7.4 mm) (Note 1) 2: PUR-cable (black, Ø 7.4 mm) (Note 1) 3: FEP-cable (black, Ø 7.4 mm) (Note 1) 9: customer |
||||||||||||||||||
| Accuracy | standard for PN > 0.4 bar 3: 0.35 % FSO standard for PN ≤ 0.4 bar 5: 0.5% FSO option 1 for PN > 0.4 bar 2: 0.25 % FSO option 2 1: 0.1 % FSO (Note 2) 9: customer |
||||||||||||||||||
| Cable length | 999: in m |
||||||||||||||||||
| Version | 000: standard 999: customer |
||||||||||||||||||
| Notes | 1: cable with integrated ventilation tube for atmospheric pressure reference 2: not in combination with SIL. |
||||||||||||||||||
If you are looking for some specific material, please write to us. Then we will try to find it for you, and send it as soon as possible.
