LMP 307i

The LMP 307i is a submersible probe from BD Sensors in stainless steel. This probe is design for continuous level measurement in water, as well as in clean or lightly polluted liquids. As the basic element of the LMP 307i is stainless steel it is designed to give exact measurements and long-term stability.

Moreover, the probe can be used for various media including:

  • Sewage water, sludge
  • Fuels and oils
  • Water.

For sales or commercial inquiries please contact us at marine@insatech.com.

Contact us now

Standard LMP 307i Features

The LMP 307i submersible probe is precise and has the following features that benefits you:

  • Nominal pressure: 0 ... 4 mH2O up to 0 ... 200 mH2O
  • Accuracy: 0,1 % FSO
  • Diameter 26,5 mm
  • Small thermal effect
  • Exceptional accuracy
  • Outstanding long-term stability.
Lmp307i 1 Bdsensors 1024X16x9

Typical applications

The LMP 307i from BD Sensors is applicable in various settings:

  • Maritime industry
  • Energy industry
  • Oil and gas industry
  • Environmental industry.

Get more information here

Additional Available Features

If you have a specific need the LMP 307i submersible probe is available with optional features like:

  • IS-version, Ex ia = intrinsically safe for gas and dust
  • Drinking water certificate according to DVGW and KTW
  • Various types of cables
  • Different kinds of seal materials.

If you have additional needs - contact us here

Lmp307i Bdsensors 1024X16x9
Lmp307i 2 Bdsensors 1024X16x9
Lmp307i 1 Bdsensors 1024X16x9
Lmp307i Bdsensors 1024X16x9
Lmp307i 2 Bdsensors 1024X16x9
Lmp307i 1 Bdsensors 1024X16x9
Lmp307i Bdsensors 1024X16x9
Insatech Medarbejdere Website MSR
For technical questions

Martin Søvind Jensen


Tel: +45 2761 4502

Email: Martin.Sovind@insatech.com

Write to Martin

Insatech Medarbejdere Website ASMI
For commercial inquiries

Astrid Mihut


Tel.: +45 5537 2095

Email: Marine@insatech.com



Contact us now

Model/ Type
Pressure

450: in bar

451: in H2O

Input

[mH2O]
4000:
4.0
1001:
10
2001:
20
4001:
40
1002:
100
2002:
200

[bar]

4000: 0.4
1001:
1.0
2001:
2.0
4001:
4.0
1002:
10
2002:
20
9999: customer

Housing

1: stainless steel 1.4404 (316L)

9: customer

Diaphragm

1: stainless steel 1.4435 (316L)

9: customer

Output

1: 4 … 20 mA / 2-wire

E: intrinsic safety 4 … 20 mA / 2 wire

3: 0 … 10 V / 3-wire

9: customer

Seals

1: FKM

3: EPDM

DVGW/KTW

3T: EPDM (Note 1)

9: customer

Accuracy

standard  for pN ≥ 0.1 bar

1: 0.1 % FSO

standard for pN < 0.1 bar

B: 0.2% FSO

9: customer

Electrical connection

1: PVC-cable (grey, Ø 7.4 mm) (Note 2)

2: PUR-cable (black, Ø 7.4 mm) (Note 2)

3: FEP-cable (black, Ø 7.4 mm) (Note 2)

4: TPE-U-cable (blue, Ø 7.4 mm) (Note 2)

DVGW/KTW

F: TPE-U-cable (blue, Ø 7.4 mm) (Note 1, 2)

9: customer

Cable length

999: in m

Special version

111: standard

999: customer

Notes

1: drinking water certification only possible with EPDM seal (code 3T) in combination with TPE-U cable (code F); not possible with IS version (explosion protection)

2: shielded cable with integrated ventilation tube for atmospheric pressure reference
