LMK 307
The LMK 307 from BD Sensors is a level probe designed to measure level continuously in water or wastewater. The basic element of the probe is a flush mounted ceramic sensor, which makes the LMK 307 applicable in all fluids that are compatible with media wetted materials.
For sales or commercial inquiries please contact us at marine@insatech.com.
The LMK 307 submersible probe is precise and has the following features that benefits you:
The LMK 307 from BD Sensors is applicable in various settings:
Moreover, the probe can be used for various media including water, fuels, and oils, as well as sewage water and sludge.
If you have a specific need the LMK 307 submersible probe is available with optional features like:
Moreover, the LMK 307 is available with various kinds of cables and elastomers according to your customer-specific operating conditions.
| Model/ Type | |||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Pressure | 380: in bar 381: in mH2O |
||||||||||||||||||
| Input | [mH2O] [bar] |
||||||||||||||||||
| Housing | 1: stainless steel 1.4404 (316L) 9: customer |
||||||||||||||||||
| Diaphragm | 2: ceramics Al2O3 96 % 9: customer |
||||||||||||||||||
| Output | 1: 4 … 20 mA / 2-wire 2: 0 … 20 mA / 3-wire 3: 0 … 10 V / 3-wire E: intrinsic safety 4 … 20 mA / 2-wire 1S: SIL2 4 … 20 mA / 2-wire ES: SIL2 with intrinsic safety, 4 … 20 mA / 2-wire 9: customer |
||||||||||||||||||
| Seals | 1: FKM 3: EPDM 9: customer |
||||||||||||||||||
| Accuracy | 5: 0.5% FSO 9: customer |
||||||||||||||||||
| Electrical connection/ cable length | PVC-cable (grey, Ø 7.4 mm) (Note 1) PUR-cable (black, Ø 7.4 mm) (Note 1) FEP-cable (black, Ø 7.4 mm) (Note 1) |
||||||||||||||||||
| Special version | 000: standard 999: customer |
||||||||||||||||||
| Notes | 1: shielded cable with integrated ventilation tube for atmospheric pressure reference. |
||||||||||||||||||
If you are looking for some specific material, please write to us. Then we will try to find it for you, and send it as soon as possible.
