Speed sensor FGL 01406

The speed sensor FGL 01406 from Horn is composed of a metallic housing that contains the sensor components and, in some cases, the electronic components. This design ensures mechanical durability and prevents interference from external circuits.

To achieve a high signal-to-noise ratio the sensor uses different parts, where each measurement task requires a distinct measurement principle, including:

Compatible output levels
Shielded cables
Plug connectors.

For sales or commercial inquiries please contact us at marine@insatech.com.

Speed sensor FGL 01406

This particular sensor is working after the same measurement principle and framework conditions like for the FGL 1/..., so the pick-ups apply to the FGL01406-.. sensor as well. However, the FGL01406-.. sensor offers a square wave signal output (PNP), ensuring safety against incorrect polarity and short circuits.

With their robust design, these pick-ups are ideal for applications in combustion engines and high-vibration machinery.

Furthermore, they have obtained approvals from recognized classification societies.

Other available Inductive Pulse and Speed Sensors

Below we have gathered the HORN selection of pulse and speed sensors. If there is a specific kind you need, which is not found here, please do not hesitate contacting us here.

Turbocharger speed sensor FGL 1/16

The speed sensor FGL 1/16 from Horn is composed of a metallic housing that contains the sensor components and, in some cases, the electronic components. This design ensures mechanical durability and prevents interference from external circuits.

To achieve a high signal-to-noise ratio the sensor uses different parts, where each measurement task requires a distinct measurement principle, including:

Compatible output levels
Shielded cables
Plug connectors.

Speed sensor FGL 01620

The speed sensor FGL 01620 from HORN can be used both at extremely low speed, and almost full stop can be detected, and it is also applicable for highspeed rotations up to 20kHz frequency. It is a preferred sensor for offshore and marine purposes because of its vigorous stainless-steel design.

The FGL 01630 has the following benefits for you:

Wide speed sensing range

Robust design
Contactless, thus, wear-free
Large air gap viable
Multifunctional sensing options.

Speed Sensor FGL01364

This FGL 01364 from HORN is an inductive phase sensor with amplifier, which is ideal for sensing objects such as:

Gear wheels
Punched discs
Integral steel shafts.

It features a coil with an oscillator circuit and amplifier. By adjusting the air gap between the object and sensor tip, voltage changes in the coil/oscillator system are detected and evaluated.
