Inductive Phase Sensor
This FGL 01364 from Dr. E. Horn is an inductive phase sensor with amplifier, which is ideal for sensing objects such as:
It features a coil with an oscillator circuit and amplifier. By adjusting the air gap between the object and sensor tip, voltage changes in the coil/oscillator system are detected and evaluated.
We deliver directly and globally to end-users, agents, and resellers.
Contact us at marine@insatech.com.
Below we have gathered the HORN selection of pulse and speed sensors. If there is a specific kind you need, which is not found here, please do not hesitate contacting us here.
The measurement principle and framework conditions for the FGL 1/... pick-ups apply to the FGL01406-.. sensor as well. However, the FGL01406-.. sensor offers a square wave signal output (PNP), ensuring safety against incorrect polarity and short circuits.
With their robust design, these pick-ups are ideal for applications in combustion engines and high-vibration machinery. They have obtained approvals from recognized classification societies.
The speed sensor FGL 01620 from HORN can be used both at extremely low speed, and almost full stop can be detected, and it is also applicable for highspeed rotations up to 20kHz frequency. It is a preferred sensor for offshore and marine purposes because of its vigorous stainless-steel design.
The FGL 01630 has the following benefits for you:
Wide speed sensing range
The speed sensor FGL 1/16 from Horn is composed of a metallic housing that contains the sensor components and, in some cases, the electronic components. This design ensures mechanical durability and prevents interference from external circuits.
To achieve a high signal-to-noise ratio the sensor uses different parts, where each measurement task requires a distinct measurement principle, including:
Horn sensors continuously measure critical parameters to ensure engine safety. They can be sold individually or integrated into our monitoring systems, providing customized solutions tailored to customer needs.
Ensuring Safety for Large Engines and Drives
Horn specialize in safety solutions for large 4-stroke and 2-stroke engines, whether used in marine vessels, power generation, or industrial applications on land.
Looking for something else? See our selection of sensors from HORN:
At Insatech, we are proud to offer our high-quality products to all customers worldwide. Whether you’re an end customer, a reseller, or an agent, you can purchase directly from us.
By choosing us, you gain direct access to all our products, eliminating the need for intermediaries. Our global distribution possibilities ensure fast and reliable delivery to your doorstep, wherever you are.
We strive to make it easy for you as an end consumer to find the products you are looking for while supporting agents and resellers looking to grow their business. Whether you’re buying for your use or resale, we’re here to meet your needs.
Discover how simple it is to work directly with a trusted global distributor – shop with confidence at Insatech today!
| Technical Specifications for TGL014xxx | |||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Supply voltage | +10...32 VDC <+10 VDC undefined work >+32 VDC destroyed |
||||||||||||||||||
| Output current max. | 180 mA |
||||||||||||||||||
| Output Signal | PNP |
||||||||||||||||||
| Polarity protection | yes |
||||||||||||||||||
| Short Circuit Protection | Yes |
||||||||||||||||||
| Function | N.O. |
||||||||||||||||||
| Mounting | Flush |
||||||||||||||||||
| Mounting distance to gear: | Depends on module frequency range: 0 Hz...1 kHz |
||||||||||||||||||
| Operating temperature | -25°C...+85°C |
||||||||||||||||||
| Operating temperature max. | -25°C...+100°C |
||||||||||||||||||
| Storage temperature | -41°C...+90°C |
||||||||||||||||||
| Cable gland insert | TPE-V |
||||||||||||||||||
| Housing | 1.4305 (AISI 303) |
||||||||||||||||||
If you are looking for some specific material, please write to us. Then we will try to find it for you, and send it as soon as possible.
